Srt Ch6020 1/8 Hv Coreless Servo Rc Nitro On-road Car

Star Refined Technology, or better known as SRT have been providing hobbyist with professional grade electronics at an affordable price for years. Their manufacturing process, R&D, and final products are top notch. A true performance first company that racers and bashers alike have come to love and trust within the radio control industry! KEY FEATURES:

Ideal for 1/8 on and off road scale applications,  as well as large scale airplanes and jets

Incredible efficiency and low power consumption

Supporting SR, SFR, SUR, SXR ultra high speed modes

2 μsec Dead Band

1-Year Limited Warranty

Item no 6.0V 7.4V 8.4V Gear Motor Case Dimension (mm) Weight (g) Speed: sec/60° Torque: kg-cm/oz-in Speed: sec/60° Torque: kg-cm/oz-in Speed: sec/60° Torque: kg-cm/oz-in CH6020 0.12 14.0/194.4 0.10 18.0/250.0 0.09 20.0/277.7 Titanium & Alu Coreless Semi-metal 41.3*20.5*38.3 69.0 Application :   1/8 Electric Car 1/8 Nitro Car 1/8 Truggy 1/8 Buggy 1/8 Short Course Truck 1/8 Monster Truck PRODUCT SPECIFICATIONS:
Type: Digital
Bearing: Dual
Motor Type: Coreless
Gear Type: Metal
Gear Material: Titanium & Aluminum
Control system: Pulse Width Control
working frequence: 1520μs / 330hz
Operating voltage: dc6.0-8.4v
Operating temperature range: -10 to + 60 degree
Operating speed (6.0v): 0.12 sec/60 degrees at no load
Operating speed (7.4v): 0.10 sec/60 degrees at no load
Operating speed (8.4v): 0.09 sec/60 degrees at no load
Stall torque (6.0v): 14.0kg.cm (194.4 oz/in)
Stall torque (7.4v): 18.0kg.cm (250.0 oz/in)
Stall torque (8.4v): 20.0kg.cm (277.7 oz/in)
Potentiometer drive: direct drive
Dimensions: 41.3x20.5x38.3 mm /1.63x0.81x1.51 in
Weight: 69.0g (2.43 oz)
Connector wire length: JR, 300mm
Genuine, new in the package part!
